Ball Capacity-10000 Ball Diameter-2.3125 Shank Diameter-1.25 Shank Length-2 5/8 IN Shank Rise-0 IN Torque-450 FT LB
2 5/16" ball 2" rise 5000#
Fits 2" couplers and accepts up to 6,000 lbs. GTW Constructed from high-strength, hot-forged steel Protected by a durable chrome-plated finish Zinc-plated hex nut and helical lock washer for secure mounting Features fine threads for superior holding strength Tested for safety to meet U.S. VESC V-5 specifications Notes: The mounting platform must be at least 3/8" thick, and the hole size must not be more than 1/16" larger in diameter than the threaded shank
Fits 2 5/16" couplers and accepts up to 7,500 lbs. GTW Constructed from high-strength, hot-forged steel Protected by a durable chrome-plated finish Zinc-plated hex nut and helical lock washer for secure mounting Features fine threads for superior holding strength Tested for safety to meet U.S. VESC V-5 specifications Notes: The mounting platform must be at least 3/8" thick, and the hole size must not be more than 1/16" larger in diameter than the threaded shank Warranty-One Year Limited Ball Capacity-7500 Ball Diameter-2.3125 Shank Diameter-1 Shank Length-2 1/8 IN Shank Rise-0 IN Torque-250 FT LB Finish-Chrome color-Silver
Fits 2 5/16" couplers and accepts up to 10,000 lbs. GTW Constructed from high-strength, hot-forged steel Protected by a durable chrome-plated finish Zinc-plated hex nut and helical lock washer for secure mounting Features fine threads for superior holding strength Tested for safety to meet U.S. VESC V-5 specifications Notes: The mounting platform must be at least 3/8" thick, and the hole size must not be more than 1/16" larger in diameter than the threaded shank Warranty-One Year Limited Shipping Weight-4.000 Ball Capacity-10000 Ball Diameter-2.3125 Shank Diameter-1.25 Shank Length-2 5/8 IN Shank Rise-0 IN Torque-450 FT LB Finish-Chrome color-Silver
These high quality hitch balls are made of top quality stainless steel for a long lasting, durable finish. All curt balls feature fine threads for superior holding strength and are tested to meet U.S. V-5 specifications. Ball Diameter: 2" Shank Diameter: 3/4" Shank Length: 2 1/8" Shank Rise: 0" Rating: 3,500 lbs Stainless Steel Construction
These high quality hitch balls feature a durable, attractive nickel chrome finish. All curt balls feature fine threads for superior holding strength and are tested to meet U.S. V-5 specifications. Ball Diameter: 2" Shank Diameter:1" Shank Length: 2 1/8" Shank Rise: 0" Rating: 6,000 lbs Finish: Chrome
CONVERT-A-BALL® Hitch System Products are your answer to multi-need trailer connections. No more wrenches, no more busted knuckles. Three interchangeable balls (1 7/8", 2" and 2 5/16") fit on the 1" shank. The 1 7/8" and 2" balls work great on the 3/4" shank. Beats the national standard SAE-J684-E for ball hitches. V-5 rated safe! 1" chromed shank for 1 7/8" 2" and 2 5/16" balls rated 10,000 lbs. 3/4" chromed shank for 1 7/8" and 2" balls rated 3,500 lbs. 3/4" stainless steel for 1 7/8" and 2" balls rated 5,000 lbs. 1" stainless steel shank rated 10,000 lbs. Safety hole drilled for cotter pin. Stainless steel slide pin with shear strength of 21,000 lbs.
Features and Benefits Ball and arm tuck under truck out of way until needed Adjustable height for various types of trailers Available in black powder coat or chrome Fits all standard 2" Receiver Hitches Multi ball configuration is easily changed for towing multiple trailers. Tech Specs Download Instructions: TS10037B Instructions Class:Class IV Fits Receiver Type:All standard 2" receivers Amount of Drop / Raise:0" to 5" - drop or raise up to 5 1/2" Weight Capacity:10,000 LB. Gross Trailer Weight / 1,000 LB. Vertical Tongue Weight Hitch Ball Size:2" & 2 5/16" Height adjustments:1" increments Finish:Black Powder Coat Weight: 28.00 lbs. Universal Fit Product: May not fit all vehicles
Adjustable Ball Mount Shanks- Used in either the up or down position to match the ball mount to any coupler height. Long hi/low shanks provide the extra length sometimes needed to obtain clearence from bumper interference.
6" drop 4" rise
2" drop
Features: Ball mount lets you hook up your trailer to your tow vehicle Shank slides into your vehicle's hitch receiver Ball platform provides mounting point for hitch ball (sold separately) Angle-cut end on shank allows for easy installation and removal Both drop and rise positions available to ensure level towing Solid, 1-piece forged steel construction Black powder coat finish covers a-coat base for superior rust protection Hitch pin and clip or hitch lock sold separately Specs: Application: 2" x 2" trailer hitch receivers Gross towing weight: 16,000 lbs Tongue weight: 2,400 lbs Length: 10-1/4" from center of hitch pin hole to center of ball hole Rise: 5" from top of inside of hitch opening Drop: 6" from top of inside of hitch opening Ball hole diameter: 1-1/4" Ball platform dimensions: 1" thick x 3" wide Requires ball shank that is at least 2-1/4" long Pin hole diameter: 5/8" Limited lifetime warranty 40332 Draw-Tite Drawbar for 2" Hitches - 5" Rise, 6" Drop - 10-1/4" Long - 16,000 lbs Reese 21332, Hidden Hitch 80144
Features: Ball mount lets you hook up your trailer to your tow vehicle Shank slides into your vehicle's hitch receiver Ball platform provides mounting point for hitch ball Angle-cut end on shank allows for easy installation and removal Both drop and rise positions available to ensure level towing Solid, 1-piece forged steel construction Black powder coat finish covers a-coat base for superior rust protection Hitch pin and clip or hitch lock sold separately Specs: Application: 2" x 2" trailer hitch receivers Gross towing weight: 16,000 lbs Tongue weight: 2,400 lbs Length: 8-1/2" from center of hitch pin hole to center of ball hole Rise: 1" from top of inside of hitch opening Drop: 2" from top of inside of hitch opening Ball hole diameter: 1-1/4" Ball platform dimensions: 1" thick x 3" wide Requires ball shank that is at least 2-1/4" long Pin hole diameter: 5/8" Limited lifetime warranty 40330 Draw-Tite Solid Forged Ball Mount - 1" Rise - 2" Drop - 16,000 lbs Reese 21330, Hidden Hitch 80142
